Customized Size And Mesh Square Gabion Planter With Galvanized

Customized Size And Mesh Options For Welded Gabion Planter With Galvanized

Welded Gabion is made of high-quality low-carbon steel wire, which is processed and formed by automatic, precise and accurate mechanical equipment in strict accordance with the standard of BS1052:1986. And the surface is passivated and plasticized by processes such as electro-galvanizing, hot-dip galvanizing, dip-plastic coating or Galfan(Zinc-aluminium coating).

The welded gabion basket details:

A) Panel: high quality galvanized panel of 50*50 or 75*75 mesh size

B) Sprial wires: good quality for same wire diameter as panel

C) Stifferens :4-8 stifferens per gabion, to make sure the gabion is more strong

The welded gabion basket connection details

1. U -clips
2. C-ring
3. Lacing wire connection
4. Hook connection

The sprial wires & hooks or stiffeners is most popular as it's more strong for usage

Welded gabion basket advantage:

1. High Structural Strength

   • Welded mesh provides superior load-bearing capacity (50% higher than woven gabions), ideal for steep slopes and heavy-duty applications.

2. Precision Geometry

   • Uniform grid patterns (e.g., 50×50mm, 100×100mm) ensure clean aesthetics for architectural and landscape designs.

3. Enhanced Durability

   • Hot-dip galvanization (≥260g/m² zinc coating) offers 25-30 years of corrosion resistance in harsh environments.

4. Rapid Installation

   • Modular design with clasp or spiral fastening systems reduces assembly time by 40% compared to woven alternatives.

5. Multifunctionality

   • Supports both stone filling (for erosion control) and soil planting (for green walls), blending functionality with ecology.

6. Low Maintenance

   • Stable structure minimizes deformation and long-term upkeep costs.
