Galvanized Gabion Wall River Bank Flood Control Erosion Protection CE ISO

Galvanized Gabion Wall River Bank Flood Control Erosion Protection CE ISO

Woven Gabion Wall for Water Control Projects

Engineered for hydraulic applications, our woven gabion wall systems provide reliable erosion protection and slope stabilization along rivers, canals and coastlines. The double-twisted hexagonal mesh structure filled with natural stone creates permeable retaining walls that dissipate water energy while preventing soil loss. Features hot-dip galvanized or PVC-coated steel wires for superior corrosion resistance in wet environments. Customizable wall heights and thicknesses to meet specific project requirements. Ideal for flood control, weirs, spillways and other water management structures requiring durable, eco-friendly solutions.

Key Features

• Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
• Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
• Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
• Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages
✓ 3x Lifespan: 50-100 years corrosion resistance
✓ Load Capacity: Up to 50kN/m² vertical pressure
✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff
✓ Modular Assembly: Interlocking panels for 70% faster installation

Applications

• Civil Engineering: Riverbank stabilization, highway embankments
• Architecture: Retaining walls, sound barriers, decorative façades
• Disaster Prevention: Flood control barriers, landslide mitigation systems
• Mining: Tailings dam reinforcement, slope retention

Customization Services

• Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
• Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
• Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)
