Easy Installation 100 mm x 80 mm Q195 Steel Wire Gabion Basket for Retaining Wall Construction

Large Image : Easy Installation 100 mm x 80 mm Q195 Steel Wire Gabion Basket for Retaining Wall Construction

Product Details:

Place of Origin:	China
Brand Name:	KN
Certification:	ISO CE
Model Number:	KN-G02

Payment & Shipping Terms:

Minimum Order Quantity:	100Pcs
Price:	USD 13-20
Packaging Details:	Wooden pallets
Delivery Time:	7 days
Payment Terms:	,T/T,L/C,Western Union
Supply Ability:	300000 sqm/month

Contact Now

Detailed Product Description

Product Name:	Gabion Basket	Material:	Q195 Steel Wire
Wire Diameter:	2-2.7mm	Mesh Hole:	68cm,810cm...
Processing Service:	Weaving	Usage:	Protect Sea Wall
MOQ:	100 Pcs	Key Word:	Stone Cage For Gabion
Highlight:	Wire Mesh Gabion Box , 100 mm x 80 mm Gabion Box , Construction metal cage retaining wall

Easy Installation Woven 100mm x 80mm Iron Wire Mesh Gabion Box

Factory direct woven mesh double twisted hexagonal Galfan box gabion for retaining wall construction and structural applications.

Product Overview

Gabion baskets are rectangular baskets manufactured from heavily galvanized, double twisted steel woven wire mesh. These single-unit constructed baskets are assembled, laced together, and filled with stone to form monolithic structures. Gabions and Reno mattresses are ideal for retaining walls, sound barriers, channel linings, slope stabilization, dams, and weirs. They are particularly effective in environmental restoration projects and promoting vegetation growth.

Key Applications

Retaining walls and structural support
Sound barriers and noise reduction
Channel linings and erosion control
Slope stabilization and earth retention
Dams, weirs, and hydraulic structures
Environmental restoration projects

Hexagonal Gabion Mesh Specifications

Material	Wire Diameter (mm)	Selvage Wire (mm)	Lacing Wire (mm)	Mesh Hole (mm)	Gabion Size (m)
Galvanizing, Hot dip galvanizing, Galfan (zinc aluminum alloy), PVC coated	2.0, 2.2, 2.4, 2.7, 3.0, 3.5, 4.0	3-4	2.0-2.2	60×80, 80×100, 100×120, 120×150, Customized	2×1×0.5, 2×1×1, 3×1×1, 4×1×2, 4×2×0.3, 6×2×0.3, Customized

Gabion Mattress Specifications

Material	Wire Diameter (mm)	Selvage Wire (mm)	Lacing Wire (mm)	Mesh Hole (mm)	Gabion Size (m)
Galvanizing, Hot dip galvanizing, Galfan (zinc aluminum alloy), PVC coated	2.0, 2.2, 2.4, 2.7, 3.0, 3.5, 4.0	3-4	2.0-2.2	60×80, 80×100, 100×120, 120×150, Customized	3×2×0.3, 4×2×0.3, 5×2×0.3, 6×2×0.3, Customized

All sizes and materials of the hexagonal gabion mesh can be customized according to your specific requirements.

Product Packaging

Gabion boxes are commonly packaged using wooden pallets. Custom packaging options are available upon request.
