Hexagonal Gabion Cage Wire Rock Retaining Wall River Bank Flood Control Erosion Protection Galvanized CE ISO

Large Image : Hexagonal Gabion Cage Wire Rock Retaining Wall River Bank Flood Control Erosion Protection Galvanized CE ISO

Product Details:

Place of Origin:	CN
Brand Name:	KN
Certification:	CE ISO SGS COC PVOC
Model Number:	gabion retaining wall

Payment & Shipping Terms:

Minimum Order Quantity:	100 pc
Price:	USD 12-17
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, T/T, Western Union, MoneyGram
Supply Ability:	1000 pc per day

Contact Now

Detailed Product Description

Features:	Flexible, Easy To Assemble, Strong And Durable	Wire Diameter:	2.0-4.0 Mm
Filling Material:	Stones Or Rocks	Mesh Type:	Double Twisted Hexagonal
Zinc Coating:	240-300 G/m2	Size:	2x1x1 M
Application:	Erosion Control, Retaining Walls, Landscaping	Surface Treatment:	Hot-dipped Galvanized
Product Name:	Retaining Walls Hexagonal Gabion Cage River Bank Flood Control Erosion Protection Galvanized CE ISO	Key Words:	Gabion Retaining Wall
Highlight:	hexagonal gabion cage , wire rock retaining wall river bank , hexagonal wire rock retaining wall

Retaining Walls Hexagonal Gabion Cage River Bank Flood Control Erosion Protection Galvanized CE ISO

The gabion box is made from low-carbon iron wire with a surface finish of galvanized, hot-dipped galvanized, galfan coated, or PVC coated, ensuring long-lasting durability and resistance to corrosion.

Key Features

Material: Hot-dip galvanized steel (Zn ≥ 250g/m²), PVC-coated options (0.5mm thickness)
Design: Hexagonal double-twist mesh, 90x110mm standard apertures (customizable)
Coatings: Epoxy/Zinc-Aluminum alloy for marine/coastal applications
Fillers: Crushed rock, recycled concrete, or vegetated soil (client-specified)

Technical Advantages
✓ 3x Lifespan: 50-100 years corrosion resistance
✓ Load Capacity: Up to 50kN/m² vertical pressure
✓ Eco-Friendly: 100% recyclable materials with zero chemical runoff
✓ Modular Assembly: Interlocking panels for 70% faster installation

Applications

Civil Engineering: Riverbank stabilization, highway embankments
Architecture: Retaining walls, sound barriers, decorative façades
Disaster Prevention: Flood control barriers, landslide mitigation systems
Mining: Tailings dam reinforcement, slope retention

Selling Units:

Single item

Single package size:

305X103X108 cm

Single gross weight:

58.000 kg

Customization Services

Sizes: 2x1x1m (standard) up to 6x2x1m (heavy-duty)
Wire Diameters: 2.2mm – 4.0mm (3.0mm recommended for high-load zones)
Colors: Metallic Silver (standard), Green/Black PVC coating (urban projects)

gabion specifications			Mesh hole modle
			8x10cm		6x8cm
Length(m)	Width(m)	Height(m)	Galvanized or PVC coated		Galvanized or PVC coated
			Mesh diameter	Zinc	Mesh diameter	Zinc
2	1	1	2.7mm	>245g/m²	2.0mm	>215g/m²
3	1	1	Side wire diameter	Zinc	Side wire diameter	Zinc
4	1	1	3.4mm	>265g/²	2.7mm	>245g/m²
6	1	1	Binding wire diameter of 2.7m		Binding wire diameter of 2.0m

Hexagonal Gabion Cage Wire Rock Retaining Wall River Bank Flood Control Erosion Protection Galvanized CE ISO 0
