275g Zinc Coated Galvanized Gabion Cages With Iron Wire Mesh

Large Image : 275g Zinc Coated Galvanized Gabion Cages With Iron Wire Mesh

Product Details:

Place of Origin:	China
Brand Name:	KN
Certification:	CE, ISO, COC,BESC
Model Number:	KNG01

Payment & Shipping Terms:

Minimum Order Quantity:	1000
Price:	USD 17-20
Packaging Details:	pallet or bundle
Delivery Time:	7
Payment Terms:	L/C,Western Union,MoneyGram,T/T
Supply Ability:	1 40-foot high containers in 7 days

Contact Now

Detailed Product Description

Product Name:	275g Zinc Coated Galvanized Iron Wire Mesh Gabion Cages For Sale	Key Word:	Gabion Cages
Material:	Galvanized Iron Wire,Low-Carbon Iron Wire,pvc Wire, Galfan Wire	Hole Shape:	Hexagonal, Double Twist
Wire Gauge:	2.4mm, 2.5mm, 2.7mm, 2.8mm, 3.05mm	Application:	Gabions,Cages,slope Protection,Fence Mesh,Construction Wire Mesh
Type:	Hexagonal Wire Mesh, Double Twist	Aperture:	80100mm,100120mm,60*80mm,etc,
Surface Treatment:	Hot Dipped Galvanized, PVCcoated, Galvanized+PVC Coated	Product Name:	Gabion Box, Gabion Box Wire Mesh,Gabion Basket,Hot Sale 2x1x1m PVC Coated Heavy Duty Gabion
Color:	Green,black,	Packing:	Pallet,Bundle
Highlight:	galvanized gabion cages , galvanized gabion basket , zinc coated gabion cages

275g Zinc Coated Galvanized Iron Wire Mesh Gabion Cages for Sale

Constructed of hot-dip galvanized steel wire (4.5mm core, 300g/m² coating), this double-twist gabion (1.5m x1m x0.5m) features 80x100mm apertures and wave-shaped diaphragms at 1m intervals for river confluence revetments. Reinforced edges (6mm wire) and stainless steel C-rings (304 grade) connect units, accommodating 80-180mm basalt infill. Integrated 50mm diameter drainage pipes (PVC) at base sections mitigate pore pressure in clay-dominated banks. Complies with JIS G 3353 for hydraulic structures, with optional sacrificial zinc anodes for brackish water interface zones.

Common Gaboin Basket Size :

Gabion Basket Size				Notes
Length (M)	Width(M)	Height(M)	Diaphragm	CBM (m³)
1	1	1	0	1
2	1	1	1	2
3	1	1	2	3
4	1	1	3	4
5	1	1	4	5
6	1	1	5	6
Other Size Accept Customized

Gabion Mattress Size				Notes
Length (M)	Width(M)	Height(M)	Diaphragm	CBM (m³)
1	1	0.3/0.5	0	0.3/0.5
2	1	0.3/0.5	1	0.6/1
3	1	0.3/0.5	2	0.9/1.5
4	1	0.3/0.5	3	1.2/2
5	2	0.3/0.5	4	3/5
6	2	0.3/0.5	5	3.6/6
Other Size Accept Customized

Product Usage:

Erosion Control: Woven gabion mesh is frequently used to stabilize slopes and riverbanks, effectively preventing soil erosion by holding back loose earth and allowing for proper water drainage.
Retaining Walls: This mesh is ideal for constructing retaining walls that not only secure hillside soil but also add an aesthetic, natural look to landscapes, making it popular in both residential and commercial projects.
Flood Protection: In areas prone to heavy rainfall or flooding, woven gabion mesh forms durable barriers that can divert water flow, thereby reducing the risk of flood damage and protecting nearby infrastructure.
Coastal Defense: The mesh is used along shorelines to stabilize sandy beaches and cliffs, mitigating the effects of wave action and protecting coastal properties from erosion.
Road and Highway Embankments: Woven gabion mesh can reinforce road embankments by retaining soil and reducing the likelihood of landslides, ensuring the long-term stability of transportation routes.
Bridge Abutments and Foundations: In bridge construction, the mesh is applied to strengthen abutments and support foundations, offering a cost-effective solution for reinforcing structural integrity.

Gabion Basket Technical Data as Followed:

Technical Data List
Parameter	Description	Typical Value / Range
Material	Base material used for constructing the mesh	HDP/Galvanized Wire, PVC Wire
Coating	Surface treatment for enhanced corrosion resistance	Galvanized, HDP Galvanized, PVC Coated
Wire Diameter	The thickness of the wires used in the mesh	Mesh Wire: 2.0~3.05mm Selvage Wire: 2.4~4.0mm Tie Wire: 2.0~2.4mm
Mesh Opening Size	The size of the openings between wires, determining the size of stones that can be contained	6080mm, 80100mm, 100120mm,120150mm
Overall Dimensions	Standard Gabion Roll and Gabion Basket Size	Gabion Roll Width: 1~4m Gabion Basket: 111m,211m,311m,411m,,511m,611m,
Lifespan	Expected service life under normal installation and maintenance conditions	Generally 6~20 years, depends on environment.
