Gabion Basket by Roll

Introduction

Key Features

• Roll-Based Design: The unique roll-based construction allows for easy transportation and installation. The gabion baskets can be unrolled directly on site, significantly reducing the time and labor required compared to traditional methods.
• High Strength and Durability: Made from heavy-duty galvanized steel wire mesh, the gabion baskets are highly resistant to corrosion and wear. They can withstand harsh environmental conditions and heavy loads, ensuring long-term stability and protection.
• Eco-Friendly: The open structure of the gabion baskets allows for natural drainage and promotes the growth of vegetation. This not only enhances the aesthetic appeal but also contributes to the overall stability of the slope by integrating with the natural environment.
• Customizable Solutions: Available in various sizes and configurations, the Gabion Basket by Roll can be tailored to meet the specific requirements of different slope conditions and project needs.

• Mesh Sizes (mm)	Gabion basket dimensions and volumes					Wire diameter
  	L(M)	W(M)	D(M)	Capacity(m³)	Number of diaphragm
  60*80 80*100 100*120	4	2	0.3	2.4	3	Mesh Wire: 2.0mm,2.2mm 2.5mm, 2.7mm,3.05mm. 2.0/3.0mm,2.2/3.2mm 2.5/3.5mm,2.7/3.7mm. selvedge wire: 2.5mm,2.7mm 3.2mm,3.4mm,3.8mm 2.5/3.5mm,2.7/3.7mm 3.2/4.2mm,3.4/4.4mm lacing wire: 2.0mm,2.2mm 2.0/3.0mm,2.2/3.2mm
  	6	2	0.3	3.6	5
  	4	2	0.23	1.84	3
  	6	2	0.23	2.76	5
  	2	1	0.5	1	1
  	3	1	0.5	1.5	2
  	4	1	0.5	2	3
  	2	1	1	2	1
  	3	1	1	3	2
  	4	1	1	4	3
  Other specifications can also be customized processing.

Application

• Stabilizing Soil: The baskets are filled with stones or other suitable materials, creating a rigid structure that holds the soil in place and prevents it from being washed away by heavy rains.
• Reducing Water Erosion: The porous design allows water to pass through while retaining the soil and debris, reducing the risk of erosion and mudslides.
• Enhancing Safety: By providing a stable barrier, the Gabion Basket by Roll helps protect infrastructure, roads, and communities located near unstable slopes.

Installation

1. Site Preparation: Clear the slope of any debris and ensure the ground is level.
2. Unrolling: Unroll the gabion baskets directly on the slope, securing them with stakes or anchors as needed.
3. Filling: Fill the with baskets stones or other suitable materials, ensuring they are packed tightly to maximize stability.
4. Final Securing: Secure the baskets with additional fasteners and interconnect them to form a cohesive structure.

Benefits

• Cost-Effective: The roll-based design reduces transportation and installation costs, making it an economical solution for large-scale projects.
• Low Maintenance: Once installed, the gabion baskets require minimal maintenance, providing long-term protection with little intervention.
• Aesthetic Appeal: The natural appearance of the filled baskets blends seamlessly with the surrounding environment, enhancing the visual appeal of the area.

Conclusion

• Cost-effective: Simply fill with stones and seal for use.
• Easy Installation: No special skills required.
• Weather-resistant: Good corrosion resistance in natural environments.
• Eco-friendly: The gaps between stones allow silt to accumulate, which is conducive to plant growth and can blend with the natural environment.
• Low Transportation Costs: Foldable for transportation and then unfolded on-site.

Application Fields

• Water Conservancy Projects: Used for embankments, riverbank protection, and waterway lining to effectively prevent scouring by water flow.
• Environmental Protection: Plays an important role in ecological restoration and soil conservation.
• Road Protection: Protects road foundations, enhancing the stability and durability of roads.
• Coastal Protection: Used in seawalls and port projects to resist wave erosion.
