Hot-Dipped Galvanized Hexagonal Gabion Mesh Cage for Slope and Riverbank Protection

Large Image : Hot-Dipped Galvanized Hexagonal Gabion Mesh Cage for Slope and Riverbank Protection

Product Details:

Place of Origin:	China
Brand Name:	KN
Certification:	CE, ISO, COC,BESC
Model Number:	KNG01

Payment & Shipping Terms:

Minimum Order Quantity:	1000
Price:	USD 12-20
Packaging Details:	pallet or bundle
Delivery Time:	7
Payment Terms:	L/C,Western Union,MoneyGram,T/T
Supply Ability:	1 40-foot high containers in 7 days

Contact Now

Detailed Product Description

Material:	Hexagonal Gabion Wall、mesh Retaining Wall Galvanized	Hole Shape:	Hexagonal, Double Twist
Wire Gauge:	2.4mm, 2.5mm, 2.7mm, 2.8mm, 3.05mm, 2.2mm, 2.0mm	Application:	Riverbank And Slope Retaining Wall Construction
Type:	Hexagonal Wire Mesh, Double Twist	Aperture:	80100mm,100120mm,60*80mm,etc,
Surface Treatment:	Hot Dipped Galvanized, PVCcoated, Galvanized+PVC Coated	Product Name:	Gabion Box, Gabion Box Wire Mesh,Gabion Basket,Hot Sale 2x1x1m PVC Coated Heavy Duty Gabion
Color:	Green, Black, Grey	Packing:	Pallet,Bundle
Usage:	Flood Control Retaining Wall, Protection,	Sample:	Available
Size:	2m1m1m,1x1x0.5m,411m,511,Customized,	Feature:	Easily Assembled,less Transport Freight,Strong And Durable, Simple Installation
Width:	2' -2m,0.914m~1.83m,0.5-2m,1M	Zinc Coated:	40-60g, 60g-80g, 270g, 245g,
Highlight:	Hot-dipped galvanized gabion cage , Hexagonal gabion mesh for slopes , Riverbank protection gabion mesh

Hot-Dipped Galvanized Hexagonal Gabion Mesh Cage for Slope and Riverbank Protection

Product Specifications

Attribute	Value
Material	Hexagonal gabion wall, mesh retaining wall galvanized
Hole shape	Hexagonal, Double Twist
Wire gauge	2.4mm, 2.5mm, 2.7mm, 2.8mm, 3.05mm, 2.2mm, 2.0mm
Application	Riverbank and Slope Retaining Wall Construction
Type	Hexagonal wire mesh, Double Twist
Aperture	80100mm, 100120mm, 60*80mm, etc.
Surface treatment	Hot Dipped Galvanized, PVC coated, Galvanized+PVC Coated
Color	Green, black, Grey
Packing	Pallet, Bundle
Usage	Flood Control Retaining Wall, Protection
Sample	Available
Size	2m1m1m, 1x1x0.5m, 411m, 511m, Customized
Feature	Easily Assembled, less transport freight, Strong and Durable, Simple installation
Width	2' -2m, 0.914m~1.83m, 0.5-2m, 1M
Zinc coated	40-60g, 60g-80g, 270g, 245g

Product Description

Hot-Dipped Galvanized Hexagonal Gabion Wall Mesh Cage for Riverbank and Slope Retaining Wall Construction.

Hexagonal Gabion Wall, mesh retaining wall galvanized Gabion Cages, Gabion Basket, Gabion Box, Mesh Gabion box.

Popular size of gabion cages in Philippines / Italy / South Africa / Tanzania / Venezuela: 2.7mm / 3.4mm / 2.2mm with 80*100 mesh hole, gabion size 2*1*1m with middle diaphragm.

Besides 2*1*1m gabion basket, we also have 1*1*1m, 3*1*1m, 4*1*1m, 5*1*1m, 6*1*1m.

Gabion iron wire basket are made of hot dipped galvanized steel wire /heavy galvanized coating steel wire/ PVC coated wires, the mesh shape is hexagonal style.

The gabion retaining wall are used widely in slope protection, mountain rock holding, gabion for river bank protection.

Standard Gabion Basket Sizes

Length (M)	Width (M)	Height (M)	Diaphragm	CBM (m³)
1	1	1	0	1
2	1	1	1	2
3	1	1	2	3
4	1	1	3	4
5	1	1	4	5
6	1	1	5	6

Other Sizes Available - Customized Orders Accepted

Product Applications

Erosion Control: Woven gabion mesh stabilizes slopes and riverbanks, preventing soil erosion while allowing proper water drainage.
Retaining Walls: Constructs aesthetically pleasing retaining walls that secure hillside soil for residential and commercial projects.
Flood Protection: Forms durable barriers to divert water flow and reduce flood damage to infrastructure.
Coastal Defense: Stabilizes shorelines against wave action, protecting beaches and coastal properties from erosion.
Road Embankments: Reinforces transportation routes by retaining soil and preventing landslides.
Bridge Construction: Strengthens abutments and foundations with cost-effective structural reinforcement.

Technical Specifications

Parameter	Description	Typical Value / Range
Material	Base material used for constructing the mesh	HDP/Galvanized Wire, PVC Wire
Coating	Surface treatment for enhanced corrosion resistance	Galvanized, HDP Galvanized, PVC Coated
Wire Diameter	The thickness of the wires used in the mesh	Mesh Wire: 2.0~3.05mm Selvage Wire: 2.4~4.0mm Tie Wire: 2.0~2.4mm
Mesh Opening Size	The size of the openings between wires	6080mm, 80100mm, 100120mm, 120150mm
Overall Dimensions	Standard Gabion Roll and Gabion Basket Size	Gabion Roll Width: 1~4m Gabion Basket: 111m to 611m
Lifespan	Expected service life under normal conditions	6~20 years (depends on environment)
