Europe Stanard Galfan Coated Outdoor Landscape Welded Gabion Wall Fence

Large Image : Europe Stanard Galfan Coated Outdoor Landscape Welded Gabion Wall Fence

Product Details:

Place of Origin:	China
Brand Name:	KN
Certification:	CE, ISO, COC,BESC
Model Number:	KN-2115

Payment & Shipping Terms:

Minimum Order Quantity:	800 set
Price:	Negotiate
Packaging Details:	pallet
Delivery Time:	15 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	1/40HQ per week

Contact Now

Detailed Product Description

Features:	Flexible, Easy To Install, Corrosion Resistant, Strong And Durable	Installation Method:	On-site Assembly, Video Installation
Key Words:	Gabion Wall Fence	Material:	Hot Dipped Galvanized Wire
Usage:	Retaining Wall	Aperture:	50×50mm, 50×100mm, 100×100mm
Box Size:	2x1x1m, 3x1x1m, 2x0.5x1m, 2x0.3x1m	Aperture Shape:	Square, Or Rectangle
Payment:	T/T	Feature:	Corrosion Resistance ,etc.
Panel Size:	2x0.5m, 1x1m, 1x0.5m	Spiral Pitch:	120mm
Zinc Coating:	30 - 240g/m²	Wire Diameter:	3.0-6.0mm
Size:	Customized Sizes Available	Spiral Wire:	3.0mm-4.0mm
Advantage:	Anti Rust, Easy Installation	Finish:	Galvanized Or PVC Coated
Package:	Packed In Bundles Or Pallets
Highlight:	Galfan coated gabion fence , Outdoor landscape welded gabion wall , Europe standard gabion fence

Europe Stanard Galfan Coated Outdoor Landscape Welded Gabion Wall Fence

Product Description

A gabion fence or wall can be a great option for both residential and commercial landscapes. The term "gabion" comes from the Italian word "gabbione," which means "big cage."

Effectively, a big cage does, in fact, form the framework of gabion walls and fences. The cages are fashioned from wire or galvanized steel and then filled with rocks, gravel, cement, natural materials, or even leftover construction materials. Gabion fences and walls make sturdy outdoor structures that provide a number of benefits.

Material has anti-rust Element, can help gabion wall fence lasting long time.

Frequently Asked Questions

Q: What are Gabions?

A: Gabions are wire mesh cages made from GALFAN-coated steel, designed to be filled with stones or other hard materials for structural or decorative purposes.

Q: What are Gabion Baskets used for?

A: Gabions serve various purposes, from controlling erosion and creating retaining walls to landscaping enhancements like garden seating, tables, or decorations.

Q: How to fill Gabion Baskets?

A: Filling a gabion basket is a straightforward process. Begin by preparing the site where the gabion will be placed. Once assembled, place larger stones at the corners and edges, then fill the interior with stones packed tightly. Periodically shake or tap the sides to settle the stones. Secure the top once filled.

Q: How to install Gabion Baskets?

A: Each Gabion arrives as a flat pack kit, including all necessary components for installation. You will need to assemble the wire panels using the helicoil wires and additional support wires provided.

Q: What stone to use in Gabion Baskets?

A: Angular stones are recommended for effective compaction and stability. Avoid rounded stones, which are more suitable for decorative purposes.

Q: What size stone for Gabion Baskets?

A: The size of the stone typically depends on the mesh hole size. With a 75mm x 75mm mesh hole size, larger stones or cobbles are ideal.

Technical Specifications

Fabric Type: Galvanized welded mesh
Tensile Strength (wire): Welded: 540 to 770 N/mm²
Weld Strength: 75% of the minimum ultimate tensile strength of the wire
Available wire thicknesses: 3.0mm, 4.0mm, 5.0mm
Mesh Aperture: 75x75mm, 50x50mm, 50x100mm, 50x200mm
Standard basket lengths: 1000mm, 1500mm or 2000mm, 500mm etc
Standard basket widths: 450mm, 500mm, 300mm, 200mm, 1000mm, 1500mm
Standard basket heights: 500mm, 1000mm
Bespoke Sizes Available

Usage Scenarios

1. Retaining Walls

Welded mesh gabions are widely used in the construction of retaining walls for stabilizing slopes, preventing soil erosion, and supporting embankments in both residential and commercial projects.

2. Erosion Control

These gabions are effective in controlling soil erosion along riverbanks, coastlines, and steep slopes by providing a stable, permeable structure that allows water flow while holding back soil.

3. Flood Protection

Welded mesh gabions can be deployed to create flood barriers or levees, protecting vulnerable areas from floodwaters and reducing damage from excessive rainfall or rising rivers.

4. Landscaping Features

Gabions are also used in landscaping to create decorative features such as garden walls, seating areas, and planters, combining functionality with aesthetic appeal.
