PVC Galvanized 60*80mm 80*100mm 100*120mm Mesh Hole Gabion Basket Retaining Wall For Earth Retention And Soil Erosion

PVC Galvanized 60*80mm 80*100mm 100*120mm Mesh Hole Gabion Basket Retaining Wall For Earth Retention And Soil Erosion

Large Image :  PVC Galvanized 60*80mm 80*100mm 100*120mm Mesh Hole Gabion Basket Retaining Wall For Earth Retention And Soil Erosion

Product Details:
Place of Origin: China
Brand Name: KN
Certification: CE ISO ASTM
Model Number: 2X1X1 3X1X1 4X1X1 5x1x1 6X2X0.3
Payment & Shipping Terms:
Minimum Order Quantity: 1000pc
Price: USD 13-25
Packaging Details: pallets
Delivery Time: 7-10 days
Payment Terms: L/C, T/T, Western Union, MoneyGram
Supply Ability: 1000 pc need 7 days
Detailed Product Description
Material: Galvanized Wire, PVC Coated Wire Wire Gauge: 2.2mm 2.7mm 3.0mm 3.4mm 3.8mm
Application: Gabions, Cages, Slope Protection, Fence Mesh, Construction Wire Mesh Mesh Size: 80*100mm, 100*120mm, 60*80mm
Feature: Easily Assembled, Less Transport Freight, Strong And Durable, Imple Installation Sample: Retaining Wall , Gabion Fence,gabion Wall
Usage: Flood Control Retaining Wall, Island, Protection, Garden And So On Size: 2m*1m*1m, 1x1x0.5m, Customized, 4*1*1m, 5*1*1
Highlight:

galvanized gabion wall retaining wall

,

galvanized gabion basket retaining wall

,

2.7mm gabion wall retaining wall

the difference between standard gabion baskets and gabion mattresses:

Standard gabion baskets and gabion mattresses are both wire mesh structures filled with materials like rocks, but they have several key differences:

1. Height and Structure

  • Standard Gabion Baskets: These are typically taller, with heights usually exceeding 1 foot (0.3 meters). They are box-like structures often used for retaining walls or slope stabilization
  • Gabion Mattresses: These are flatter and shorter, with heights generally ranging from 0.15 to 0.5 meters (6 to 20 inches). Their flat design makes them ideal for covering and protecting surfaces like riverbeds and slopes

2. Application

  • Standard Gabion Baskets: Commonly used for vertical applications such as constructing retaining walls, creating architectural features, or reinforcing slope.
  • Gabion Mattresses: Primarily used for horizontal applications, such as lining riverbanks, channels, and slopes to prevent erosion

3. Flexibility and Stability

  • Standard Gabion Baskets: Their height and box-like structure provide more vertical support and are suitable for areas where height is needed for stabilization
  • Gabion Mattresses: Their flat design offers better stability on slopes and in areas with high water flow, making them more adaptable to dynamic environments

4. Installation and Aesthetics

  • Standard Gabion Baskets: Often stacked vertically to create taller structures. They are more visible and can be used for decorative purposes in landscaping
  • Gabion Mattresses: Typically laid horizontally and are less visible once installed. They are more functional and less commonly used for aesthetic purposes

5. Material and Construction

  • Both standard gabion baskets and gabion mattresses are usually made from double-twisted hexagonal mesh, which provides flexibility and durability,However, the specific dimensions and configurations may vary based on the intended use.
In summary, the choice between standard gabion baskets and gabion mattresses depends on the specific requirements of the project, including the terrain, water flow conditions, and desired aesthetic outcomes



Types of Gabions

  1. Standard Gabion Baskets:
    • These are rectangular or square wire mesh containers filled with rocks or other materials. They are commonly used for retaining walls, slope stabilization, and erosion control .
  2. Gabion Mattresses:
    • These are shorter and flatter than standard gabions, often used to protect surfaces from wave erosion or similar forces. They are ideal for riverbeds and shorelines
  3. Trapions:
    • These have a trapezoidal cross-section, designed for stacking to create a sloping face rather than a stepped one. This design is particularly useful for aesthetic and functional purposes .
  4. Bastions:
    • These are gabions lined internally with a membrane, typically of nonwoven geotextile, to allow the use of granular soil fill instead of rocks .

Applications of Gabions

  1. Civil Engineering and Erosion Control:
    • Gabions are used to stabilize slopes, shorelines, and stream banks against erosion. They are also used in the construction of retaining walls, noise barriers, temporary flood walls, and small dams
  2. Military Applications:
    • Historically, gabions were used as military fortifications to protect soldiers and artillery from enemy fire. Today, they are often used to protect forward operating bases (FOBs) against explosive threats
  3. Landscaping and Architectural Uses:
    • Gabions are increasingly used in landscaping for their aesthetic appeal. They can be used to create garden walls, benches, fire pits, and other decorative elements. Their flexibility and permeability make them suitable for both functional and aesthetic purposes .
  4. River and Channel Linings:
    • Gabions are used to line riverbanks and channels to prevent erosion and control water flow. They can also be used to construct stepped weirs for river training and flood control

Advantages of Gabions

  1. Durability and Longevity:
    • The lifespan of gabions depends on the durability of the wire mesh, which can last up to 60 years with proper coatings such as PVC or galvanization .
  2. Flexibility and Permeability:
    Gabions can adapt to ground movement and allow water to pass through, reducing the risk of water pressure buildup and erosion
  3. Ease of Construction:
    • Gabions are relatively easy to install and can be filled with locally available materials, reducing transportation costs
  4. Aesthetic Appeal:
    • The natural appearance of rock-filled gabions can blend well with the environment and provide a rustic aesthetic .

Maintenance and Considerations

  1. Inspection and Repair:
    • Regular inspections are necessary to detect any damage or wear. Any issues should be promptly addressed to maintain the structural integrity of the gabion .
  2. Vegetation and Water Management:
    • Vegetation growing within the gabion should be managed to prevent structural damage. Water seepage should be monitored to avoid excessive moisture buildup .
  3. Environmental Impact:
    • While gabions are effective for erosion control, they may have limited habitat value. In some cases, they can be enhanced with vegetation to improve ecological benefits
Gabions are versatile and durable structures that offer a range of benefits in both functional and aesthetic applications. Their long history and continued use in modern engineering and landscaping highlight their effectiveness and adaptability.
PVC Galvanized 60*80mm 80*100mm 100*120mm Mesh Hole Gabion Basket Retaining Wall For Earth Retention And Soil Erosion 0
PVC Galvanized 60*80mm 80*100mm 100*120mm Mesh Hole Gabion Basket Retaining Wall For Earth Retention And Soil Erosion 1
